TL;DR

China’s centralized infrastructure and renewable buildout enable it to deploy AI at gigawatt-scale power capacity, offsetting lower chip performance. The US remains dominant in chips but faces constraints at the physical power delivery layer.

China’s AI infrastructure buildout leverages its centralized planning and renewable energy capacity to operate at gigawatt-scale power throughput, contrasting with the US, which is constrained by fragmented grid and permitting challenges. This structural difference is reshaping global AI deployment dynamics.

Recent developments show China has added over 430 gigawatts of wind and solar capacity in 2025, surpassing US renewable additions by approximately eight times. Its extensive ultra-high-voltage (UHV) transmission network, spanning over 40,000 kilometers, enables the country to route renewable energy from production hubs to AI data centers across regions, effectively bypassing the US’s grid bottlenecks.

Meanwhile, US AI data centers, such as Meta’s Hyperion or OpenAI’s Stargate, require gigawatt-scale power infrastructure that faces significant regulatory, siting, and transmission hurdles. The US relies on off-grid gas turbines, nuclear contracts, and complex interconnection queues, which slow deployment. Despite superior chip performance, US infrastructure constraints limit the physical delivery of electricity necessary for AI scaling.

Chinese AI chips, like Huawei’s Ascend 910C, perform at roughly 60% of NVIDIA’s H100 inference levels and lack native FP8/FP4 support. However, China compensates by deploying these less capable chips across a power infrastructure that is scaled via renewable energy and extensive transmission, making the system-level capacity comparable or even superior at scale.

The Gigawatt Gap — Thorsten Meyer AI
GIGAWATT
● DISPATCH / MAY 2026
THORSTEN MEYER AI · AI ENERGY & INFRASTRUCTURE · § 01
ENERGY & INFRA · 01
US-CHINA · AI POWER STACK
Essay · Structural-Comparison Analysis · 2026-05-17

The gigawatt gap.
Why China is structurally
positioned for AI power
and the US is engineering
around its grid.

The US dominates AI on chips, infrastructure, models, and applications — except on the layer that physically runs them.
Frontier AI data centers now need 100 MW to start and 1–2 GW at full buildout. Meta Hyperion targets 5 GW; OpenAI Stargate 10 GW; AWS 12 GW. The US reaches this scale through behind-the-meter PPAs · off-grid gas · nuclear restarts · ERCOT regulatory arbitrage · because 2,300 GW are stuck in 5-year interconnection queues. China reaches it through the NDRC’s Eastern Data Western Compute initiative · 45 UHV projects · 40,000 km · 340 GW cross-regional capacity · routing demand to western hubs co-located with 430 GW of new wind+solar added in 2025 alone. Even though Huawei’s Ascend 910C runs at ~60% H100 inference perf, the system-level asymmetry inverts the comparison: US perf-per-watt advantage vs. China watts-without-bound advantage. The gap is constitutional, not technical.
3.89 TW
China total installed
power capacity end 2025
2,300 GW
US interconnection queue
5-year average wait
40K km
China UHV transmission
45 projects · 340 GW capacity
~60%
Ascend 910C inference perf
vs. H100 · compensated by watts
STARGATE 10 GW· HYPERION 5 GW· AWS 12 GW· MICROSOFT 2 GW/YR· 2,300 GW QUEUE· 5-YR WAIT· PJM $29→$329/MW-DAY· ON-SITE GAS +1,800%· CHINA 3.89 TW· 1.8 TW WIND+SOLAR· 430 GW ADDED 2025· 4 TRILLION KWH RENEWABLE· 40,000 KM UHV· 45 UHV PROJECTS· 340 GW CAPACITY· ASCEND 910C ~60% H100· CLOUDMATRIX 384 / 300 PFLOPS· HUAWEI 1M DIES 2025· DEEPSEEK ON H800s· NDRC MANDATE· STARGATE 10 GW· HYPERION 5 GW· AWS 12 GW· MICROSOFT 2 GW/YR· 2,300 GW QUEUE· 5-YR WAIT· PJM $29→$329/MW-DAY· ON-SITE GAS +1,800%· CHINA 3.89 TW· 1.8 TW WIND+SOLAR· 430 GW ADDED 2025· 4 TRILLION KWH RENEWABLE· 40,000 KM UHV· 45 UHV PROJECTS· 340 GW CAPACITY· ASCEND 910C ~60% H100· CLOUDMATRIX 384 / 300 PFLOPS· HUAWEI 1M DIES 2025· DEEPSEEK ON H800s· NDRC MANDATE·
FIG. 01 — THE GIGAWATT SCALE
What frontier AI infrastructure now requires
The unit of measure has shifted from megawatts to gigawatts in 24 months · the binding constraint with it
Starter site
100 MW
Single building
~500 MW
Training sweet spot
1–2 GW
Meta Hyperion
5 GW
Stargate target
10 GW
Stargate Abilene’s 1.2 GW peak is half the system peak of El Paso Electric (serving 465,000 customers). AWS Indiana’s 2.2 GW at full buildout = approximately half the residential electricity consumption of all Indiana households combined. The four largest US hyperscalers have committed ~$650B to AI infrastructure across 2025–2026. Capital is not the constraint. The rate at which transformers can be manufactured, transmission permitted, and generation interconnected is.
FIG. 02 — THE AMERICAN BOTTLENECK
2,300 GW stuck · five-year wait · PJM prices 10x
The capacity exists in the queue · it cannot reach commercial operation at the rate AI buildouts require
Capacity in
interconnection queue
2,300 GW
Approx. US total
installed capacity
~1.3 TW
Of 2000-2019 requests
built by end-2024
13%
2026 capacity from
on-site generation
30%
PJM capacity price
DY 2024-25 → 2026-27
$29→$329
Wait times have more than doubled in 15 years. Onsite gas generation capacity has grown ~1,800% since 2025. Stargate Abilene runs 300 MW of on-site simple-cycle gas turbines; Meta Hyperion is anchored on a $3.2B 2 GW combined-cycle gas plant with $550M shouldered by Louisiana residents; xAI Colossus 2 trucks gas turbines into suburban Memphis. The hyperscalers are not solving the grid problem. They are routing around it.
FIG. 03 — THE TWO POWER STACKS
Constitutional fragmentation vs. centralised mandate
The same gigawatt-scale problem · two structurally different state-architectures solving it
UNITED STATES · WORKAROUND STACK
Five layers · routing around the grid
L1
Behind-the-meter PPAs · TMI restart · Talen-Susquehanna · Microsoft-Chevron
L2
Off-grid gas turbines · xAI Colossus · Stargate Abilene 300 MW · Hyperion $3.2B plant
L3
On-site share scaling · 0% → 30% of new capacity in 12 months
L4
ERCOT regulatory arbitrage · Texas HB 1500 · independent of FERC · 2-3x faster
L5
Executive-order acceleration · DOE Section 403 · FERC PJM order · April 30 2026 deadline
CHINA · CENTRALISED STACK
One mandate · five aligned layers
L1
NDRC mandate (2022) · Eastern Data Western Compute · 8 hubs · 10 cluster sites
L2
UHV backbone · 45 projects · 40,000+ km · 340 GW cross-regional capacity
L3
Western renewable hubs · Guizhou · Ningxia · Inner Mongolia · Gansu · co-located
L4
State Grid + China Southern · unified transmission build · single operator
L5
PUE ≤1.25 mandate · 50 intelligent computing centers · 300 EFLOPS target 2025
The US coordination cost runs through Cleanview · RMI · FERC · DOE · 7 ISOs/RTOs · 50 state utility commissions · local zoning. In China the coordination cost is the NDRC’s planning meeting. This produces speed and scale at the cost of democratic legitimacy and local accountability — both costs are real, and both are routed back to consumers downstream.
FIG. 04 — THE RENEWABLE FOUNDATION
The asymmetry under the chip comparison
China’s renewable buildout operates at roughly 8x the US pace · this is the foundation everything else rests on
United States · 2025
36 GW
Wind + utility solar + distributed
solar additions 2025
~1.3 TW
Total installed power
generation capacity
368 GW
Operating wind + solar
installed base
~26%
Renewable share
of capacity
~8×
2025 capacity
add ratio
China · 2025
430+ GW
Wind + solar additions
2025 alone
3.89 TW
Total installed power
capacity end 2025
1.8 TW
Combined wind + solar
installed capacity
>60%
Renewable share
of capacity
Chinese renewable generation reached ~4 trillion kWh in 2025 — exceeding the entire EU-27 electricity consumption (3.8 trillion kWh). China’s single-day peak load (1.506 TW) is now higher than total US installed capacity. 2025 Chinese energy infrastructure investment: ~$500B across generation, grids, and energy security — roughly the same scale as the four-hyperscaler US AI infrastructure commitment, but spent on the foundation AI runs on rather than on AI itself.
FIG. 05 — THE ASYMMETRIC SUBSTITUTION
Perf-per-watt vs. watts-without-bound
Different binding constraints · per-chip comparisons miss the system-level inversion
UNITED STATES STACK
High perf
Low watts
Perf-per-watt advantage at the chip · grid-bounded at the system
Frontier chip
H100/H200/B200
FP precision
FP8 / FP4
Software stack
CUDA / PyTorch
Rack power
130+ kW NVL72
Binding constraint:
grid + transmission capacity
CHINA STACK
Lower perf
More watts
Watts-without-bound advantage at the system · chip-bounded per unit
Domestic chip
Ascend 910C ~60% H100
FP precision
No native FP8/FP4
Memory
HBM2E (older)
System scale
CloudMatrix 384 / 300 PFLOPS
Binding constraint:
chip performance / FP precision
Production scale: ~1M Huawei Ascend dies shipping in 2025 · ~2M in 2026 · Ascend 960 (Q4 2027) projected H200-comparable. DeepSeek V3/R1 trained on degraded H800s at ~1/10 the US comparable-model compute cost — the lesson is not that DeepSeek had better chips; it is that algorithmic efficiency plus power-throughput substitution can produce frontier-competitive models with constrained silicon. If Chinese chips are 60% as performant per-chip but Chinese power can deploy them at 2-3x density without grid constraint, the system-level capability approaches parity.
The US has perf-per-watt advantage. China has watts-without-bound advantage. These are asymmetric substitutes — not the same axis. When the perf-per-watt side is bounded by grid capacity and the watts-without-bound side is bounded by chip performance, the binding constraint differs.
Thorsten Meyer · The Gigawatt Gap · Energy & Infrastructure 01

Implications of the Gigawatt-Scale Power Divide

This structural difference could redefine global AI leadership. While the US maintains technological superiority in chip performance, China’s ability to deploy AI infrastructure at gigawatt-scale—enabled by centralized planning and renewable energy—may allow it to accelerate AI deployment and capabilities. The shift from chip-focused to power-focused scaling challenges traditional assumptions about technological dominance and highlights the importance of infrastructure policy and national strategy in AI progress.

Amazon

high voltage ultra-high-voltage transmission cables

As an affiliate, we earn on qualifying purchases.

As an affiliate, we earn on qualifying purchases.

China’s Centralized Infrastructure and US Grid Fragmentation

Historically, the US has led in AI innovation, driven by advanced chips, software, and applications. However, recent trends indicate that physical infrastructure—particularly power delivery—has become a bottleneck for frontier AI data centers requiring 100 MW to 2 GW or more. China’s approach, centered on large-scale renewable buildout and extensive UHV transmission, allows it to bypass some of these constraints, giving it an operational advantage at the system level.

The US faces regulatory hurdles, permitting delays, and grid limitations that inhibit rapid gigawatt-scale deployment. In contrast, China’s centralized governance enables swift infrastructure expansion, aligning renewable generation with AI demand across vast regions.

“The US AI infrastructure buildout is constrained at the layer where physical infrastructure has to be permitted, sited, and energized. China is not constrained at that layer.”

— Thorsten Meyer

Amazon

renewable energy data center power supplies

As an affiliate, we earn on qualifying purchases.

As an affiliate, we earn on qualifying purchases.

Unresolved Questions on Infrastructure and Policy Impact

It remains unclear whether US infrastructure improvements, regulatory reforms, or technological efficiency gains will close the gigawatt gap. The long-term impact of China’s centralized renewable and transmission strategy versus the US’s fragmented grid is still developing, and future policy shifts could alter the current trajectory.

Amazon

large-scale AI data center power infrastructure

As an affiliate, we earn on qualifying purchases.

As an affiliate, we earn on qualifying purchases.

Next Steps in AI Infrastructure Development and Policy

In the coming 24 months, attention will focus on whether the US can implement reforms to mitigate grid and permitting bottlenecks, or if China’s infrastructure strategy will further solidify its lead at the system level. Monitoring policy changes, renewable deployment rates, and technological advances will be critical to understanding future AI deployment capacity.

Amazon

off-grid gas turbines for data centers

As an affiliate, we earn on qualifying purchases.

As an affiliate, we earn on qualifying purchases.

Key Questions

Why does power infrastructure matter more than chip performance in AI scaling?

AI data centers require massive amounts of electricity; the physical delivery of power determines the feasible scale of deployment. Even with high-performance chips, without sufficient power infrastructure, scaling AI at the frontier remains limited.

How does China’s renewable energy strategy support its AI infrastructure?

China’s large-scale renewable buildout and extensive ultra-high-voltage transmission enable it to supply gigawatt-scale power to AI data centers across regions, bypassing some of the US’s grid constraints.

Will US policy reforms or technological improvements bridge the gigawatt gap?

This remains uncertain. While efficiency gains and regulatory reforms could help, the fundamental structural differences suggest that the US may face ongoing constraints unless it addresses its grid and permitting issues.

Does lower chip performance in China negate its advantage in deployment capacity?

No. Despite lower per-chip performance, China’s ability to deploy chips across a scaled-up power infrastructure effectively compensates, enabling comparable or greater system-level AI capacity.

What are the implications for global AI leadership?

The country that can scale AI infrastructure efficiently—whether through chip innovation or power infrastructure—will hold a significant advantage in AI capabilities and deployment speed over the next decade.
